High Efficient Candy Making Equipment For Jelly Small Candy Easy Operating

China Shanghai Huanxuan Food Machinery Co., Ltd. certification
China Shanghai Huanxuan Food Machinery Co., Ltd. certification
I'm Online Chat Now

High Efficient Candy Making Equipment For Jelly Small Candy Easy Operating

High Efficient Candy Making Equipment For Jelly Small Candy Easy Operating
High Efficient Candy Making Equipment For Jelly Small Candy Easy Operating

Large Image :  High Efficient Candy Making Equipment For Jelly Small Candy Easy Operating

Product Details:

Place of Origin: Shanghai, China (Mainland)
Brand Name: Huanxuan
Certification: CE Certificate
Model Number: HX-150 to 300

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Detailed Product Description
Condition: New Application: Candy
Voltage: 380V Power(W): 32.5kw
Weight: 2000kg Warranty: One Year
After-sales Service Provided: Engineers Available To Service Machinery Overseas Machine Materials: Stainless Steel Small Candy Making Machine
Model: HX-150-300 Color: Silver Small Candy Making Machine
Capacity: 150kg/h~300kg/h Name: High Efficient Factory Price Jelly Small Candy Making Machine
Type: Automatic Function: Multifunctional Small Candy Making Machine
Serivice: He Plant Layout Design, Assembling And Installation Key Word: Small Candy Making Machine
High Light:

candy production line

,

candy and toffee making machine

High efficient factory price jelly small candy making machine





1. Machine Brief Introduction of jelly small candy making machine :

This soft candy processing line is an advanced continuous plant for making different sizes and colors of soft/gummy candies. It is a ideal equipment which can produce out good quality products with one color or two colors and saving of both the manpower and the space occupied. This depositing line consists of dissolving cooker, gear pump, storage strainer, storage tank, discharging pump, color and flavor mixer, depositor, cooling tunnel, electric control cabinet etc.

2. Feature of jelly small candy making machine :

1) PLC /computer process control available;

2) An LED touch panel for easy operating;

3) The main body is made of Stainless Steel

4) Optional (mass) flowing controlled by Frequency inverters;

5) In-line injection, dosing and pre-mixing techniques for the proportional addition of liquid;

6) Dosing pumps for the automatic injection of colors, flavors and acids;

7) Use automatic steam control system instead of manual steam valve which controls a stable steam supply to the microfilm cooker.

3. Specifications of jelly small candy making machine :

Model

HX150

HX300

Production capacity

150kg/h

300kg/h

Rated Depositing times

                   60 (n/min)

Weight ofcandy

Two color

                   1-6g/pc

One color

power

Voltage

                       380v

power

18kw

27kw

Compressed air needed

Dosage

0.2m3/min

0.25 m3/min

Pressure

                  0.4-0.6mpa

Conditions needed for cooling system

           20-25℃     55% humidity

Dimension

9400*1100*1800mm

10000*1600*1800

Gross Weight

4000kg

4500kg







Q: How can we get detailed quotation form you?
To save your valuable time, please kindly provide information as follows with your inquiry:
1. The Target Capacity (kg/h) you need;
2. Type of candy picture you want to make;

3. Type of heating device (electric or steam);
4. Your plant length and width if have;


Q:Do you a  professional food machienry manufacturer?
Yes, we do. Our team have more than 20 yesrs experience , we are professioanl for the food equipment and export business. And we are know what the customer needs, we can supply
good quality products and competitive price to you.


Q: What methods of Payment are Acceptable?
1) Telegraphic transfer(T/T). If you order is standard machine, just need T/T 30% as deposit before production, then 70% T/T balance before shipment.
2) Western Union
3) L/C: 100% L/C Irrevocable at sight
